Consilia - Analog and Digital Hardware Development
Analog and Digital Hardware Development

Services

Our team is able to develop a HW module in all its product phases:
  • predefinition phase (feasibility study for marketing purposes)
  • prototyping (simulations, schematic, PCB layout, communication with PCB producer and assembly house)
  • series production (testing)
  • phase-out (EOL components substitution)

Analog HW

Team with 18+ years of experience:
  • analog and RF hardware
  • competence in RF frontends for SDR platforms (up to 8GHz) including AD and DA converters
  • customized high-end solutions close to aero-space performance
  • high-performance oscillators which overcome the standard market products in performance/price ratio
  • our lab owns RF generators, spectrum analyzers, oscilloscopes

Digital HW

Extensive experience:
  • Xilinx and Intel (Altera) FPGA portfolios including VHDL design
  • Our team is used to create a PCB with debugging capabilities including standard interfaces (e.g. JTAG)
  • In the near past we successfully developed series products containing PCIexpress, 10Gb Ethernet, DDR3/4, USB 3.1, JESD204
  • Long-term experience with standard communication interfaces like SPI, I2C etc.

Applications Areas

Our services cover the following areas:
  • Automotive
  • Embedded solutions
  • IoT communication
  • RF and wireless communication
  • Networking and Basestations

Design Tools

Main design tools used during the development:
  • Cadence Allegro, Mentor Expedition, Altium
  • NI AWRDE – MWO
  • LTcad
  • Version control - svn, git, JIRA

References

Rohde & Schwarz
Measurement Devices, Air Traffic Control
Hytera
TETRA Network Base-Stations
Netcope
100G Ethernet Solutions
Invasys
Mobile Network Solutions
Automotive Lighting
Automotive
Hella
Automotive
Honeywell
IoT, Safety Products, Aerospace

Contact

We are permanently looking for new partners, business opportunities, and challenging projects. Please use one of the contact details to come in touch with us.

You are always welcome to visit our design lab!
